GIG

Description

Overview

GENERAL Inclinometer MEMS technology.

High performance, high IP rating, resistance to shock and vibrations, and high electromagnetic compatibility make this sensor suitable for mobile hydraulic applications.

Developed to guarantee a robust, high-performance solution for applications such as agricultural vehicles, earth-moving machines, and hoisting equipment.

Description



Measurement Range
±10° ±15° ± 20° ± 30° ± 45° ± 60°± 85° (dual XY axis)
360° (±180°) (single Z axis)
Supply voltage
+5Vdc (only for 0.5..4.5Vdc output); +10…+36VDC (see output signal for right supply voltage)
Output signal
0.5…4.5V RATIOMETRIC (supply +5Vdc); 0.5…4.5V; 0…10V; 4…20mA; CANopen
Electrical connections
M12 connector output; cable output
Resolution
0.05° (±10° to ±20°); 0.05°(±30°); 0.1°(±45°); 0.1°(±60°); 0.1°(±85°); 0.1° (±180°) analog output; 0.05° CANopen output
Linearity
< ±0.5% FS
Working temperature and Coefficient of temperature
-40°C … +85°C thermal drift < 0.01°/°C in the range (T=-10°C..+60°C)
Vibrations
20g between 10 Hz … 2000 Hz secondo IEC 60068-2-6
Shock
Pulse on 3 axes; 50g 11 ms secondo IEC 60068-2-27
Electromagnetic compatibility
2014/30/EU Electromagnetic Compatibility (EMC)
IP Protection Level
M12 connector output (IP67); cable output (IP X9K)
Housing body
PBT
